TUNEX HQ - Impact Sound Insulation Membrane
  Nov 9, 2020 - 16:14
  Turkey

Product Description

TUNEX HQ - Impact Sound Insulation Membrane / Underlayment

TUNEX HQ is obtained by recycling end of life tires (ELT). TUNEX HQ is an insulation material in the form of a mat used under screed or floor covering for the purpose of impact sound insulation. It is used in different thicknesses and surface forms depending on the acoustic performance to be aimed. It is a long-lasting material that is resistant to mold, fungus, bacteria and water, and is a recyclable material that contributes greatly to LEED and BREEAM scoring, and complies with local and international regulations.

Field of Use

All building types (screed, parquet or under carpet)

Technical Information / Product Data

Material: Rubber

Thickness (mm): 3, 4.5, 5, 8/4, 15/10

Width (m): 0,6

Impact Sound Insulation (ΔLw = 20.7-26.7)

100% recycling

Quality Assurance Certification: ISO, LEED, BREEAM

References:

Kıbrıs Rocks Hotel
Metropol Istanbul
Nidapark Bomonti
TEM Media Center
Ramada Hotel
Yassıada Congress Center

Draft Technical Specifications
